单坡帐篷结构具有单倾斜屋顶线，其中一侧明显高于另一侧。 Monopitch 是传统帐篷的突破性替代品，具有独特的屋顶形状，重新定义了户外场地。
|
Fastup Tent Item No. |
Width (m) |
Bay distance (m) |
Side height (m) |
Ridge height C(m) |
Ridge height A(m) |
Roof Pitch |
Main frame profile (m) |
Wind load (km/h) |
Snow load (KN/m2) |
Popular Szie |
| MONO10/4000 | 10m | 5m | 4m | 6.5m | 6.31m | 18° | 204x110mm / 200x120mm | 100km/h | 0.3 Kn/m2 | 20m/30m/50m |
| MONO15/4000 | 15m | 5m | 4m | 8.18m | 8.03m | 18° | 250x111mm / 250x120mm | 100km/h | 0.3 Kn/m2 | 20m/30m/50m |
| MONO20/4000 | 20m | 5m | 4m | 9.73m | 18° | 300x120mm | 100km/h | 0.3 Kn/m2 | 30m/40m/50m | |
