Wedding Party Event Shelter 10X20M 10M X 20M 10 By 20 20X10 20M X 10M

Wedding Party Event Shelter 10X20M 10M X 20M 10 By 20 20X10 20M X 10M
Tents are widely used for outdoor events, 10x20m and 20x20m are two of the most popular sizes for outdoor party tents, which can take about 200 and 400 guests in banquet seating.
The outdoor party tents are usually served with interior roof lining and curtain, which make the tents even more presentable and elegant. Sometimes the events are required to have open sidewalls, meaning there will be no wall around the outdoor party tent so that our guests under the tent can enjoy the natural cool wind and fresh air. But when the weather is hot, we’d better put the sidewalls on and turn on the air-conditioners, or the guests may feel like burning even under the tent shelter.

Party Tent all size dimension

Fastup Tent
Item No.

Width
(m)

Bay Distance (m)

Side height (m)

Ridge height (m)

Main frame profile
(mm)

Roof Pitch

Wind Load (km/h)

Snow Load (Kn/m2)

SPT3/2300

3m

3m

2.3m

2.85m

60X48mm

22°

100

0.3

SPT4/2300

4m

3m

2.3m

3.05m

60X48mm

22°

100

0.3

SPT5/2500

5m

3m

2.5m

3.45m

82X48mm

22°

100

0.3

SPT6/2500

6m

3m

2.5m

3.65m

82X48mm

22°

100

0.3

SPT8/2500

8m

3m

2.5m

4.05m

82X48mm

22°

100

0.3

SPT9/2500

9m

3m

2.5m

4.2m

100X48mm

22°

100

0.3

SPT10/2500

10m

3m

2.5m

4.4m

100X48mm

22°

100

0.3

MPT12/2500

12m

5m

2.5m

4.9m

122X68mm

22°

100

0.3

MPT15/3000

15m

5m

3m

5.35m

166X88mm

18°

100

0.3

MPT18/3000

18m

5m

3m

5.8m

166X88mm

18°

100

0.3

LPT20/4000

20m

5m

4m

7.2m

203X110mm

18°

100

0.3

LPT22/4000

22m

5m

4m

7.45m

203X110mm

18°

100

0.3

LPT25/4000

25m

5m

4m

7.95m

250X110mm

18°

100

0.3

LPT30/4000

30m

5m

4m

8.7m

255X110mm

18°

100

0.3

LPT40/4000

40m

5m

4m

10.2m

340X170mm

18°

100

0.3

LPT50/4000

50m

5m

4m

11.9m

340X170mm

18°

100

0.3

LPT60/4000

60m

5m

4m

13.5m

340X170mm

18°

100

0.3



Material and Quality

FRAME

Hard pressed anodized aluminum alloy 6061/T6

ROOF COVER

850g/sqm block-out Double PVC coated polyester, Fire retardant, Water Proof

SIDEWA

650g/sqm or 850g/sqm PVC; Glass Pannel sidwall, ABS sidewall, Sandwich Wall

CONNECTION

Hot Dip Gavanized Steel Connector, Aluminum roof connection



Structure details
